Deploy Lambda@Edge with AWS CDK and TypeScript

6th February 2022

Hi,

Lambda@Edge are Lambdas that are executed in the AWS Cloudfront Locations. That can increase performance and reduce latency compared to normal Lambda. Cloudfront together with Lambda@Edge can also being used as a proxy for a private S3 asset bucket.

A token issued by Cognito is then used by Lambda@Edge to validate if the requester is allowed to access the S3 asset. I will describe more about this in the next blogpost. Here we will talk about how to create a Lambda@Edge with AWS CDK and Typescript.

AWS CDK Lambda@Edge

Lambda@Edge already exists in the CDK cloudfront package https://docs.aws.amazon.com/cdk/api/v1/docs/aws-cloudfront-readme.html. Unfortunately, it is not directly possible to write the Lambda code with TypeScript as we are already used to it like from the NodejsFunction.

Well not with me! I took a closer look at NodejsFunction and EdgeFunction and transferred the TypeScript functionality from NodejsFunction to EdgeFunction. I simply define a CDK construct which is extended by EdgeFunction and take functions and properties from NodejsFunction. And here is the code of my nodejs-edge-function.ts construct:

import * as cloudfront from '@aws-cdk/aws-cloudfront';
import * as core from '@aws-cdk/core';
import * as bundling from '@aws-cdk/aws-lambda-nodejs/lib/bundling';
import * as lambda from '@aws-cdk/aws-lambda';
import * as fs from 'fs';
import * as path from 'path';
import { BundlingOptions } from '@aws-cdk/aws-lambda-nodejs';
import { PackageManager } from '@aws-cdk/aws-lambda-nodejs/lib/package-manager';
import { callsites, findUpMultiple } from '@aws-cdk/aws-lambda-nodejs/lib/util';


/**
 * environment variables are not supported for Lambda@Edge
 */
export interface NodejsEdgeFunctionProps extends Omit<lambda.FunctionOptions, 'environment'> {
    /**
   * Path to the entry file (JavaScript or TypeScript).
   *
   * @default - Derived from the name of the defining file and the construct's id.
   * If the `NodejsFunction` is defined in `stack.ts` with `my-handler` as id
   * (`new NodejsFunction(this, 'my-handler')`), the construct will look at `stack.my-handler.ts`
   * and `stack.my-handler.js`.
   */
    readonly entry?: string;

    /**
     * The name of the exported handler in the entry file.
     *
     * @default handler
     */
    readonly handler?: string;

    /**
     * The runtime environment. Only runtimes of the Node.js family are
     * supported.
     *
     * @default Runtime.NODEJS_14_X
     */
    readonly runtime?: lambda.Runtime;

    /**
 * Whether to automatically reuse TCP connections when working with the AWS
 * SDK for JavaScript.
 *
 * This sets the `AWS_NODEJS_CONNECTION_REUSE_ENABLED` environment variable
 * to `1`.
 *
 * @see https://docs.aws.amazon.com/sdk-for-javascript/v2/developer-guide/node-reusing-connections.html
 *
 * @default true
 */
    readonly awsSdkConnectionReuse?: boolean;

    /**
     * The path to the dependencies lock file (`yarn.lock` or `package-lock.json`).
     *
     * This will be used as the source for the volume mounted in the Docker
     * container.
     *
     * Modules specified in `nodeModules` will be installed using the right
     * installer (`npm` or `yarn`) along with this lock file.
     *
     * @default - the path is found by walking up parent directories searching for
     *   a `yarn.lock` or `package-lock.json` file
     */
    readonly depsLockFilePath?: string;

    /**
     * Bundling options
     *
     * @default - use default bundling options: no minify, no sourcemap, all
     *   modules are bundled.
     */
    readonly bundling?: BundlingOptions;

    /**
     * The path to the directory containing project config files (`package.json` or `tsconfig.json`)
     *
     * @default - the directory containing the `depsLockFilePath`
     */
    readonly projectRoot?: string;

    /**
     * The stack ID of Lambda@Edge function.
     *
     * @default - `edge-lambda-stack-${region}`
     * @stability stable
     */
    readonly stackId?: string;
}

export class NodejsEdgeFunction extends cloudfront.experimental.EdgeFunction {

    constructor(scope: core.Construct, id: string, props: NodejsEdgeFunctionProps) {
        const handler = props.handler ?? 'handler';
        const runtime = props.runtime ?? lambda.Runtime.NODEJS_14_X;
        const entry = path.resolve(findEntry(id, props.entry));
        const architecture = props.architecture ?? lambda.Architecture.X86_64;
        const depsLockFilePath = findLockFile(props.depsLockFilePath);
        const projectRoot = props.projectRoot ?? path.dirname(depsLockFilePath);
        super(scope, id, {
            ...props,
            runtime,
            stackId: props.stackId,
            code: bundling.Bundling.bundle({
                ...props.bundling ?? {},
                architecture,
                runtime,
                depsLockFilePath,
                entry,
                projectRoot,
            }),
            handler: `index.${handler}`,
        });
    }
}

/**
 * Checks given lock file or searches for a lock file
 */
function findLockFile(depsLockFilePath?: string): string {
    if (depsLockFilePath) {
        if (!fs.existsSync(depsLockFilePath)) {
            throw new Error(`Lock file at ${depsLockFilePath} doesn't exist`);
        }

        if (!fs.statSync(depsLockFilePath).isFile()) {
            throw new Error('`depsLockFilePath` should point to a file');
        }

        return path.resolve(depsLockFilePath);
    }

    const lockFiles = findUpMultiple([
        PackageManager.PNPM.lockFile,
        PackageManager.YARN.lockFile,
        PackageManager.NPM.lockFile,
    ]);

    if (lockFiles.length === 0) {
        throw new Error('Cannot find a package lock file (`pnpm-lock.yaml`, `yarn.lock` or `package-lock.json`). Please specify it with `depsFileLockPath`.');
    }
    if (lockFiles.length > 1) {
        throw new Error(`Multiple package lock files found: ${lockFiles.join(', ')}. Please specify the desired one with \`depsFileLockPath\`.`);
    }

    return lockFiles[0];
}

/**
 * Searches for an entry file. Preference order is the following:
 * 1. Given entry file
 * 2. A .ts file named as the defining file with id as suffix (defining-file.id.ts)
 * 3. A .js file name as the defining file with id as suffix (defining-file.id.js)
 * 4. A .mjs file name as the defining file with id as suffix (defining-file.id.mjs)
 */
function findEntry(id: string, entry?: string): string {
    if (entry) {
        if (!/\.(jsx?|tsx?|mjs)$/.test(entry)) {
            throw new Error('Only JavaScript or TypeScript entry files are supported.');
        }
        if (!fs.existsSync(entry)) {
            throw new Error(`Cannot find entry file at ${entry}`);
        }
        return entry;
    }

    const definingFile = findDefiningFile();
    const extname = path.extname(definingFile);

    const tsHandlerFile = definingFile.replace(new RegExp(`${extname}$`), `.${id}.ts`);
    if (fs.existsSync(tsHandlerFile)) {
        return tsHandlerFile;
    }

    const jsHandlerFile = definingFile.replace(new RegExp(`${extname}$`), `.${id}.js`);
    if (fs.existsSync(jsHandlerFile)) {
        return jsHandlerFile;
    }

    const mjsHandlerFile = definingFile.replace(new RegExp(`${extname}$`), `.${id}.mjs`);
    if (fs.existsSync(mjsHandlerFile)) {
        return mjsHandlerFile;
    }

    throw new Error(`Cannot find handler file ${tsHandlerFile}, ${jsHandlerFile} or ${mjsHandlerFile}`);
}

/**
* Finds the name of the file where the `NodejsFunction` is defined
*/
function findDefiningFile(): string {
    let definingIndex;
    const sites = callsites();
    for (const [index, site] of sites.entries()) {
        if (site.getFunctionName() === 'NodejsEdgeFunction') {
            // The next site is the site where the NodejsFunction was created
            definingIndex = index + 1;
            break;
        }
    }

    if (!definingIndex || !sites[definingIndex]) {
        throw new Error('Cannot find defining file.');
    }

    return sites[definingIndex].getFileName();
}

As we can see, I have taken many private functions from the NodejsFunction. The construct is now imported into my CDK stack as follows:

import { NodejsEdgeFunction } from './nodejs-edge-function';

...

const imageAccessFunction = new NodejsEdgeFunction(this, 'edge');

The Lambda@Edge code now behaves as we are used to from the NodejsFunction. The TypeScript Lambda can now be created in the src folder with the name STACK.edge.ts. Third-party libraries can be kept in the root package.json. Webpack as module bundler provides an efficient transformation into the JavaScript format.

Summary

Mega cool or? With a few steps, I can now write my Lambda@Edge in TypeScript as usual. Of course, I plan to contribute the code to the aws-cdk repo. Hopefully my PR will be accepted soon and you won't have to bother importing my code here. Do you find my construct helpful? If so write me!
